| Model No. | FTTH Drop Cable |
|---|---|
| Brand Name | OEM |
| place of origin | China |
| Number of cores | 1 |
| Fiber Count | 1F |
| Fiber Type | G652D/G657A |
| Strength Member | Steel Wire/FRP |
| Cable Jacket | LSZH |
| Cable size (Height * width) | 2.0(±0.1) mm × 3.0(±0.2)mm |
| Cable weight | 8.0KG±1KG |
Product description
FTTH Cable directly connected to their homes, their bandwidth, wavelength and transmission technology type are not restricted. The optical fiber unit id positioned in the centre. Two parallel strength member are placed at the two sides. The cable is completed with a black LSZH sheath.
Application
1.Used as access building cable.
2.Used in indoor cabling, especially used for fiber to the home.
Characteristics
1. Good mechanical and environmental characteristic
2. Flame retardant characteristics meet the requirements of relevant standards
3. Soft ,flexible ,easy to lay and splice,and with big capacity data transmission
4. Meet various requirements of market and clients
Cable construction details
| Items | Description | |
| Number of fiber | 1cores/2cores | |
| Fiber type | G652D/G657A | |
| Strength member | material | Galvanized steel wire/FRP/KFRP |
| diameter | 2*(0.5~0.8)mm | |
| Outer sheath | material | LSZH |
| diameter | 1.7±0.2mm | |
| Cable size (Height * width) | 2.0(±0.1) mm × 3.0(±0.2)mm | |
| Cable weight | 8.0KG±1KG | |
